TRI-POD Three Axis Sliding Table
As a parallel kinematic multi-axis mechanism, the HiPA electric hexapod eliminates mechanical stacking errors while delivering micron-level precision and high dynamic response. It provides precise 6-degree-of-freedom (6-DOF) control in 3D space - combining linear motion (X/Y/Z) and rotational movement (about X/Y/Z axes) - making it ideal for precision spatial positioning and alignment calibration applications.
-
Quick Response, Dynamic Response Time<10ms
-
Micron Leve Positioning Accuracy
-
Support Non-standard Customization
-
Product Advantages
-
Specifications
-
Application Solutions
Product Advantages
-
Micron-Level Precision & Fast Response
Delivers micron-level positioning accuracy with dynamic response time under 10ms, ensuring smooth, reliable, and precise motion control.
-
Compact & Highly Integrated Design
Small footprint with low center of gravity, incorporating high-precision machined components for stable operation and smooth performance.
-
Streamlined Connectivity
Built-in cable management simplifies connections, improving system cleanliness and integration efficiency.
-
Flexible Multi-DOF Control
Supports multi-degree-of-freedom flexible control, capable of simulating complex motion trajectories for advanced applications.
-
Modular & Durable Construction
Modular joint units allow independent replacement to minimize downtime, while industrial-grade durability ensures low maintenance costs and long service life.
Specifications
-
TRI-POD Three Axis Sliding Table
-
X-axis Travel / Accuracy
-
Y-axis Travel / Accuracy
-
Z-axis Travel / Accuracy
-
Tx-axis Travel / Accuracy
-
Ty-axis Travel / Accuracy
-
Rz-axis Travel / Accuracy
-
Drive Type
-
Speed
-
Main Material
-
Surface Treatment
-
Horizontal Load Capacity
-
Installation Method
-
Weight
-
Dimensions
-
TRI-POD Three Axis Sliding Table
-
X-axis Travel / Accuracy±2.0mm / ±5μm
-
Y-axis Travel / Accuracy±2.0mm/±5μm
-
Z-axis Travel / Accuracy±5mm/±5μm
-
Tx-axis Travel / Accuracy±2.5°/ ±0.01°
-
Ty-axis Travel / Accuracy±2.5°/ ±0.01°
-
Rz-axis Travel / Accuracy±2°/ ±0.01°
-
Drive TypeLead Screw
-
Speed5mm/s; 1°/s
-
Main MaterialAL7075 + Cast Iron
-
Surface TreatmentBlack Hard Anodizing
-
Horizontal Load Capacity60 N
-
Installation MethodHorizontal Mount
-
Weight3.6kg
-
Dimensions130 × 130 × 150 mm
-
Application Solutions
-
Consumer ElectronicsWith deep expertise in lasers, JPT provides advanced optical calibration and inspection systems for electronics. Combining optical design, vision algorithms, and motion control, we deliver intelligent, high-precision solutions that empower the industry.
Learn More -
Pan-SemiconductorJPT integrates core laser and automation technologies for wafer trimming, ceramic cutting, glass drilling, and marking. Our high-performance lasers and intelligent equipment enhance precision, yield, and process consistency across MLCC, LTCC, and IC substrates.
Learn More -
New EnergyFor batteries, JPT offers one-stop laser solutions from cell processing to PACK assembly. In photovoltaics, our applications span glass drilling, cell cleaving, PERC hole drilling, PL inspection, and perovskite patterning—driving efficient green energy manufacturing.
Learn More
