Haze Tester
The Haze Meter is a high-precision optical inspection instrument designed to measure material transmittance and haze values. The system provides accurate optical characterization of transparent and semi-transparent materials, making it suitable for material quality inspection, optical performance evaluation, and industrial process control.
The instrument integrates an optimized optical path design, high-stability photoelectric sensors, and intelligent compensation algorithms, enabling highly accurate and repeatable measurements. It supports measurement of different sample geometries, including flat and curved surfaces, ensuring reliable performance across various applications.
-
0~100%Measurement range
-
0.01%Haze & transmittance resolution
-
Product Advantages
-
Specifications
-
Application Solutions
Product Advantages
-
Advanced Optical Accuracy
Proprietary calibration algorithms, adjustable spot size, and broad spectral range ensure precise and versatile material characterization.
-
Flexible & Non-Destructive Testing
Non-contact optical measurement with multi-angle goniometer supports diverse configurations without damaging samples.
-
High-Speed & Reliable Performance
Fast acquisition with excellent repeatability guarantees consistent results in demanding applications.
-
Compact & Scalable Design
Vibration-resistant construction with modular architecture enables easy integration into varied system environments.
-
User-Friendly Operation & Reporting
Intuitive graphical interface with multiple export formats simplifies workflows and enhances data analysis efficiency.
Specifications
-
T% & Haze Tester
-
Measurement Items
-
Measurement and Light Source Standards
-
Measurement Range
-
Test Mode
-
Detector
-
Measurement Wavelength
-
Measurement Samples
-
Collimated Spot Size
-
Light Measurement Angle
-
Repeatability
-
Reproducibility
-
Measurement Time
-
Interface
-
Power Supply Voltage
-
Temperature
-
Humidity
-
Size
-
Equipment Weight
-
T% & Haze Tester
-
Measurement ItemsTransmittance T%&Haze%
-
Measurement and Light Source StandardsSupports ASTM and ISO standards/CIE-A&CIE-C&CIE-D65 standard lighting sources
-
Measurement RangeT% (0-100%), Haze% (0.1-90%)
-
Test ModeTotal haze/Individual haze (haze vs. wavelength)
-
DetectorSpectrometer
-
Measurement Wavelength380-1100 nm
-
Measurement SamplesFlat glass & Curved glass
-
Collimated Spot Size>1mm (adjustable)
-
Light Measurement Angle±7°
-
RepeatabilityT% & Haze% 6*σ < 0.5%
-
ReproducibilityTolerance percentage<10%
-
Measurement Time~0.5s-2s (depending on the size of the light spot)
-
InterfaceUSB 2.0480 Mbps (compatible with USB 1.1); RS-232 (five wire system)
-
Power Supply Voltage220 V
-
Temperature25±5℃
-
Humidity<90% non-condensing
-
Size340 x 255 x 555 mm
-
Equipment Weight25 kg
-
