PS IR/GR/UV Picosecond Laser
Application Advantages
Central Wavelength: 1064 nm (532 nm / 355 nm )
Pulse Width: 6~10 ps
Beam Quality: M2 < 1.3
Average Power: 30W(@1064nm)/10W (@ 355 nm)
Repetition Rate: Single Shot to 1MHz
Pulse Picking Mode: Burst Mode, Position Synchronized Output
(PSO)
JPT-PS picosecond laser series are based on the novel application approach with a compact dual-layers cavity and smart opto-electronic design. It adapts to fine industrial machining environment and merging scientific characterizations. Presently infrared and ultraviolet version are available for the customs with a minimum pulse duration around 6 ps. JPT picosecond laser possesses powerful functions providing the POD and Burst Mode, the tunable repetition rate ranges from single short to 1MHz.
| Parameter Unit | Unit | Parameter | ||||||
| Model | JPT-PS-UV-5 | JPT-PS-UV-10 | JPT-PS-GR-15 | JPT-PS-GR-40 | JPT-PS-IR-20 | JPT-PS-IR-30 | JPT-PS-IR-80 | |
| Wavelength | nm | 355 | 532 | 1064 | ||||
| Repetition Rate | MHz | Single pulse ~2 | ||||||
| Average Power | W | ≥5 | ≥10 | ≥15 | ≥40 | ≥20 | ≥30 | ≥80 |
| Single Pulse Energy | μJ | 12.5 | 25 | 40 | 80 | 50 | 75 | 150 |
| Pulse Width | ps | <10 | ||||||
| Power Stability | hrs | <2%@8 | ||||||
| Pulse to Pulse Stability | - | <3% | <2% | <3% | ||||
| M² | - | ≤1.3 | ||||||
| Polarization Orientation | - | Horizontal | Vertical | Horizontal | ||||
| Linear Polarization Ratio | mm | >100:1 | ||||||
| Beam Circularity | - | >90% | ||||||
| Divergence (Full Angle) | mrad | <2 | ||||||
| Beam Diameter Output | mm | 1.5 ± 0.5 (Customizable) | ||||||
| Power Configuration | V | 24 (DC) | 36 (DC) | 24 (DC) | 36 (DC) | |||
| Power Consumption | W | <600 | <1000 | <600 | <1000 | |||
| Cooling Method | - | Water cooled | ||||||
| Operating Condition | ℃ | Temperature 15-35℃; Humidity<65% (no condensation) | ||||||
| Recommend Water Cooling Temperature | ℃ | 21 | ||||||
| Starting Time (Warm) | min | <10 | ||||||
| Starting Time (Cool) | min | <30 | ||||||
| Laser Weight | kg | 55 | 60 | 55 | 60 | |||
| Dimensions(L×W×H) | mm | 732 × 416 × 140 | 736 × 415 × 129.5 | 732 × 416 × 140 | 736 × 415 × 129.5 | |||
